Detailed Image:

Upper Part

Using 1.0mm thick cold-roll steel sheet for the shell, 1.0mm thick 304 stainless steel inner , made through cutting, bending, welding, stamping and grinding, with surface treatment of acid washing, phosphating and epoxy electrostatic powder coating, impact test qualified, lined with 5mm thick compact panel, providing three-stage exhaust design, control panel is located on the side plate for convenient observation and operation.

Lower Part

Using 1.0mm cold-roll steel sheet , providing adjustable feet which consist of stainless steel screw, nylon cover and rubber material, with anti-skidding, shock absorbing, chemical resistant, corrosion resistant and strong bearing abilities.

Viewable Window

Using :≥5mm anti-explosion toughened glass, available to stop at any height of the rain slider, the main window can slide around.

Top -solid physiochemical board / Epoxy Resin board , thickness 13/16/19mm, catcher 26mm (optional)

Accessories

Socket - anti-dust, splash proof safety socket with automatic closing lid, size of 60×60mm, 10A/16A /220V

Light - round energy saving light hidden in top ceiling, not directly contact with the air in the fume hood, easy to be replaced

Control Panel - multi-function socket, lighting , fan and fan valve control (optional)

Sink - using imported PP material , chemical resistant , corrosion resistant and organic resistant

Tap - using copper material with high gloss epoxy powder spayed surface, acid and alkali resistant, corrosion resistant, providing single/double/triple outlet types for choice, with detachable nozzle and ergonomic PP handle

Sewer System - using high-density imported PP trap, corrosion resistant, chemical resistant and organic resistant, with filtering and smelly odor blocking function.

Faucet: collapsible , stainless steel .

Specific Standards

Available Opening Height : 0—700 mm

Face Velocity : 0.4—0.6m/s

Noise :<60db,

Airflow Speed:1080—1700m3/h;

Electricity :AC220V—380V/0.09—4kw

Remark for export :

l  Production time: Sample order: 7 working days; Whole order: 15-20 working days.

l  All products are knocked down packing with hard carton and pallet.

l  Our product is simply assembly with install video\ instruction\ installation drawing.

l  The above quotation is FOB Guangzhou price,

l  Payment terms:Sample order, 100%T/T;  Wholesale order: T/T 30% deposit in advance, T/T  70% balance before delivery.

l  Warranty: 2 year warranty.

l  OEM order , customized item are warmly welcome.

l  Our Advantage:

l  1. Factory with advanced laser equipment and so on with high quality standard.

l  2.Superior R&D ability, sastified before & after-sale customer service.

l  3.Short customizing time with competitive price.

Why choose us ?

1.OEM and ODM service.Directly manufacturing factory with competitive price and quality control,we check all material when we start to bulk product  productions

2.Professional advice to help you purchase the products you wanted

3.Professional export service team servers in the deal

4.Customization service is available ,OEM business is appreciated

5.We will inspect and test all products material carefully to ensure no damage and lost

6.The success of our cooperation can be guaranteed for our company is a credible and honest partner.

How to place an order ?

1.Contact by e-mail or trade manager for specified items

2.Contract signed , 40% deposit in advance

3.Bulk productions

4.Balance payment before shipment .

5.Shipping send original documents or tele-release goods

6.Quality warranty for 2 years after shipment .

Do you have products in stocks?

Some itemS we reserve stocks .If there is no any stocks, we will inform you with details in the reply of your require.

How much will the shipping charges be ?

This is depends on the size of your shipment and the method of shipping .When inquire about the shipping charges , we hope that you let us know the detailed information such as the codes and the quantity .Your favorable method of shipping .( by sea or by air ) and your designated port or air port .We will be gradeful if you can spare us some minutes to help us since it will enable us to evaluate the cost based on the information provided .

Can I visit your factory ?

Sure ,We are a manufacturer of lab furniture in Guangzhou ,China .Please contact us in advance and will make an appointment with you.CE certificated lab furniture with gas valve
