Chemistry Medical Pathology Laboratory Laminar Flow Fume Cupboard Equipment

GET A QUOTE

Detailed Image:

Upper Part

Using 1.0mm thick cold-roll steel sheet for the shell, 1.0mm thick 304 stainless steel inner , made through cutting, bending, welding, stamping and grinding, with surface treatment of acid washing, phosphating and epoxy electrostatic powder coating, impact test qualified, lined with 5mm thick compact panel, providing three-stage exhaust design, control panel is located on the side plate for convenient observation and operation.

Lower Part

Using 1.0mm cold-roll steel sheet , providing adjustable feet which consist of stainless steel screw, nylon cover and rubber material, with anti-skidding, shock absorbing, chemical resistant, corrosion resistant and strong bearing abilities.

Viewable Window

Using :≥5mm anti-explosion toughened glass, available to stop at any height of the rain slider, the main window can slide around.

Top -solid physiochemical board / Epoxy Resin board , thickness 13/16/19mm, catcher 26mm (optional)

Accessories

Socket - anti-dust, splash proof safety socket with automatic closing lid, size of 60×60mm, 10A/16A /220V

Light - round energy saving light hidden in top ceiling, not directly contact with the air in the fume hood, easy to be replaced

Control Panel - multi-function socket, lighting , fan and fan valve control (optional)

Sink - using imported PP material , chemical resistant , corrosion resistant and organic resistant

Tap - using copper material with high gloss epoxy powder spayed surface, acid and alkali resistant, corrosion resistant, providing single/double/triple outlet types for choice, with detachable nozzle and ergonomic PP handle

Sewer System - using high-density imported PP trap, corrosion resistant, chemical resistant and organic resistant, with filtering and smelly odor blocking function.

Faucet: collapsible , stainless steel .

Specific Standards

Available Opening Height : 0—700 mm

Face Velocity : 0.4—0.6m/s

Noise :<60db,

Airflow Speed:1080—1700m3/h;

Electricity :AC220V—380V/0.09—4kw

Key attributes

Industry-specific attributes

material

metal

Other attributes

general use

Commercial Furniture

type

Laboratory Furniture

place of origin

China

brand name

SFS

model number

Cutting bench

Product name

Laboratory clean bench flow fume hood

Color

Cutomized

Worktop

Solid core physicochemical board

Certification

Function

Work Station

Name

Workshop

Application

Chem Laboratory

Structure

C-frame

Accessory

Water Sink

Warranty

1 Year

Packaging and delivery

Packaging Details

For Container order the Normal Carton Packing and for the LCL Shipment Wooden Case packing to ensure the safety of goods, knock down packing, kraft Board Bound with iron Belts Externally, Each unit with assemble instruction in the packing carton.

Port

FOB Guangzhou
